Edelkrone HeadONE

Size (L x W x H)

3.90 x 3.75 x 1.87 in (99 x 95 x 47.5 mm)

Weight

20.4 oz (580 g)

Recommended camera load Pan

15 lb (6.8 kg)

Mounting options

3/8"-16 mounting screw on top. 3/8"-16 mounting port on bottom. (3/8"-16 to 1/4"-20 reducer bushing for mounting port are provided.)

Min. step size

0.00061 degree

Max. speed

25.7 degree/sec

Number of axes

Single

Max. rotation

∞ x 360°

Motor type

Step motor with ultra high-res encoders.

Supported fps

All

Power input

Requires x1 Canon LP-E6 type battery to operate. Battery bracket included. Battery not included.

Battery life

With 14.4 Wh energy (1 Canon LP-E6 battery is 14.4 Wh)
Operates 3 hours (continuously at full speed)
Shoots 15000 photographs (in Time-Lapse mode)

Shutter trigger cable socket

2.5 mm (shutter trigger cable sold seperately)

Can be paired with

SliderONE v2, Slide Module v2 / v3, DollyONE, DollyPLUS

Mobile device connection

2.4 GHz direct link for inter-device communication and BLE for pairing / mobile phone connection

App. compatibility

iOS 11.0 or later & Android 5.0 or later

Materials

CNC machined aluminum & stainless steel components.
